Disk formatting is the process of preparing a data storage device such as a hard disk drive, solid-state drive, floppy disk or USB flash drive for initial use. In some cases, the formatting operation may also create one or more new file systems. The first part of the formatting process that performs basic medium preparation is often referred to as "low-level formatting".[1] Partitioning is the common term for the second part of the process, making the data storage device visible to an operating system.[1] The third part of the process, usually termed "high-level formatting" most often refers to the process of generating a new file system.[1] In some operating systems all or parts of these three processes can be combined or repeated at different levels[NB 1] and the term "format" is understood to mean an operation in which a new disk medium is fully prepared to store files.
As a general rule,[NB 2] formatting a disk leaves most if not all existing data on the disk medium; some or most of which might be recoverable with special tools.[4]Special tools can remove user data by a single overwrite of all files and free space.[5]
History[edit]
A block, a contiguous number of bytes, is the minimum unit of storage that is read from and written to a disk by a disk driver. The earliest disk drives had fixed block sizes (e.g. the IBM 350 disk storage unit (of the late 1950s) block size was 100 6 bit characters) but starting with the 1301[6] IBM marketed subsystems that featured variable block sizes: a particular track could have blocks of different sizes. The disk subsystems on the IBM System/360 expanded this concept in the form of Count Key Data (CKD) and later Extended Count Key Data (ECKD); however the use of variable block size in HDDs fell out of use in the 1990s; one of the last HDDs to support variable block size was the IBM 3390 Model 9, announced May 1993.[7]
Modern hard disk drives, such as Serial attached SCSI (SAS)[8] and Serial ATA (SATA)[9] drives, appear at their interfaces as a contiguous set of fixed-size blocks; for many years 512 bytes long but beginning in 2009 and accelerating through 2011, all major hard disk drive manufacturers began releasing hard disk drive platforms using the Advanced Format of 4096 byte logical blocks.[10][11]
Floppy disks generally only used fixed block sizes but these sizes were a function of the host's OS and its interaction with its controller so that a particular type of media (e.g., 5¼-inch DSDD) would have different block sizes depending upon the host OS and controller.
Optical discs generally only use fixed block sizes.
Disk formatting process[edit]
Formatting a disk for use by an operating system and its applications typically involves three different processes.[NB 3]
- Low-level formatting (i.e., closest to the hardware) marks the surfaces of the disks with markers indicating the start of a recording block (typically today called sector markers) and other information like block CRC to be used later, in normal operations, by the disk controller to read or write data. This is intended to be the permanent foundation of the disk, and is often completed at the factory.
- Partitioning divides a disk into one or more regions, writing data structures to the disk to indicate the beginning and end of the regions. This level of formatting often includes checking for defective tracks or defective sectors.
- High-level formatting creates the file system format within a disk partition or a logical volume. This formatting includes the data structures used by the OS to identify the logical drive or partition's contents. This may occur during operating system installation, or when adding a new disk. Disk and distributed file systemmay specify an optional boot block, and/or various volume and directory information for the operating system.
Low-level formatting of floppy disks[edit]
The low-level format of floppy disks (and early hard disks) is performed by the disk drive's controller.
Consider a standard 1.44 MB floppy disk. Low-level formatting of the floppy disk, normally writes 18 sectors of 512 bytes to each of 160 tracks (80 on each side) of the floppy disk, providing 1,474,560 bytes of storage on the disk.
Physical sectors are actually larger than 512 bytes, as in addition to the 512 byte data field they include a sector identifier field, CRC bytes (in some cases error correction bytes) and gaps between the fields. These additional bytes are not normally included in the quoted figure for overall storage capacity of the disk.
Different low-level formats can be used on the same media; for example, large records can be used to cut down on inter-record gap size.
Several freeware, shareware and free software programs (e.g. GParted, FDFORMAT, NFORMAT and 2M) allowed considerably more control over formatting, allowing the formatting of high-density 3.5" disks with a capacity up to 2 MB.
Techniques used include:
- head/track sector skew (moving the sector numbering forward at side change and track stepping to reduce mechanical delay),
- interleaving sectors (to boost throughput by organizing the sectors on the track),
- increasing the number of sectors per track (while a normal 1.44 MB format uses 18 sectors per track, it is possible to increase this to a maximum of 21), and
- increasing the number of tracks (most drives could tolerate extension to 82 tracks: though some could handle more, others could jam).
Linux supports a variety of sector sizes, and DOS and Windows support a large-record-size DMF-formatted floppy format.[citation needed]
Low-level formatting (LLF) of hard disks[edit]
Hard disk drives prior to the 1990s typically had a separate disk controller that defined how data was encoded on the media. With the media, the drive and/or the controller possibly procured from separate vendors, users were often able to perform low-level formatting. Separate procurement also had the potential of incompatibility between the separate components such that the subsystem would not reliably store data.[12]
User instigated low-level formatting (LLF) of hard disk drives was common for minicomputer and personal computer systems until the 1990s. IBM and other mainframe system vendors typically supplied their hard disk drives (or media in the case of removable media HDDs) with a low-level format. Typically this involved subdividing each track on the disk into one or more blocks which would contain the user data and associated control information. Different computers used different block sizes and IBM notably used variable block sizes but the popularity of the IBM PC caused the industry to adopt a standard of 512 user data bytes per block by the middle 1980s.
Depending upon the system, low-level formatting was generally done by an operating system utility. IBM compatible PCs used the BIOS, which is invoked using the MS-DOS debug program, to transfer control to a routine hidden at different addresses in different BIOSes.[13]
Transition away from LLF[edit]
Starting in the late 1980s, driven by the volume of IBM compatible PCs, HDDs became routinely available pre-formatted with a compatible low-level format. At the same time, the industry moved from historical (dumb) bit serial interfaces to modern (intelligent) bit serial interfaces and word serial interfaces wherein the low level format was performed at the factory.
Today, an end-user, in most cases, should never perform a low-level formatting of an IDE or ATA hard drive, and in fact it is often not possible to do so on modern hard drives because the formatting is done on a servowriter before the disk is assembled into a drive in the factory.[14][15]
Disk reinitialization[edit]
 | This section needs additional citations for verification. (July 2009) (Learn how and when to remove this template message) |
While it is generally impossible to perform a complete LLF on most modern hard drives (since the mid-1990s) outside the factory,[16] the term "low-level format" is still used for what could be called the reinitialization of a hard drive to its factory configuration (and even these terms may be misunderstood).
The present ambiguity in the term low-level format seems to be due to both inconsistent documentation on web sites and the belief by many users that any process below a high-level (file system) format must be called a low-level format. Since much of the low level formatting process can today only be performed at the factory, various drive manufacturers describe reinitialization software as LLF utilities on their web sites. Since users generally have no way to determine the difference between a complete LLF and reinitialization (they simply observe running the software results in a hard disk that must be high-level formatted), both the misinformed user and mixed signals from various drive manufacturers have perpetuated this error. Note: Whatever possible misuse of such terms may exist (search hard drive manufacturers' web sites for all these terms), many sites do make such reinitialization utilities available (possibly as bootable floppy diskette or CD image files), to both overwrite every byte and check for damaged sectors on the hard disk.
Reinitialization should include identifying (and sparing out if possible) any sectors which cannot be written to and read back from the drive, correctly. The term has, however, been used by some to refer to only a portion of that process, in which every sector of the drive is written to; usually by writing a specific value to every addressable location on the disk.
Traditionally, the physical sectors were initialized with a fill value of
0xF6 as per the INT 1Eh's Disk Parameter Table (DPT) during format on IBM compatible machines. This value is also used on the Atari Portfolio. 8-inch CP/M floppies typically came pre-formatted with a value of 0xE5,[17] and by way of Digital Researchthis value was also used on Atari ST and some Amstrad formatted floppies.[NB 4] Amstrad otherwise used 0xF4 as a fill value. Some modern formatters wipe hard disks with a value of 0x00 instead, sometimes also called zero-filling, whereas a value of 0xFF is used on flash disks to reduce wear. The latter value is typically also the default value used on ROM disks (which cannot be reformatted). Some advanced formatting tools allow configuring the fill value.[NB 5]
One popular method for performing only the zero-fill operation on a hard disk is by writing zero-value bytes to the drive using the Unix dd utility with the /dev/zerostream as the input file and the drive itself (or a specific partition) as the output file.[18] This command may take many hours to complete, and can erase all files and file systems.
Another method for SCSI disks may be to use the sg_format[19] command to issue a low-level SCSI Format Unit Command.
Zero-filling a drive is not necessarily a secure method of erasing sensitive data[not in citation given], or of preparing a drive for use with an encrypted filesystem.[20]
Partitioning[edit]
Partitioning is the process of writing information into blocks of a storage device or medium that allows access by an operating system. Some operating systems allow the device (or its medium) to appear as multiple devices; i.e. partitioned into multiple devices.
On MS-DOS, Microsoft Windows, and UNIX-based operating systems (such as BSD, Linux and Mac OS X) this is normally done with a partition editor, such as fdisk, GNU Parted, AOMEI Partition Assistant or Disk Utility. These operating systems support multiple partitions.
In current IBM mainframe OSs derived from OS/360 and DOS/360, such as z/OS and z/VSE, this is done by the INIT command of the ICKDSF utility.[21] These OSs support only a single partition per device, called a volume. The ICKDSF functions include creating a volume label and writing a Record 0 on every track.
Floppy disks are not partitioned; however depending upon the OS they may require volume information in order to be accessed by the OS.
Partition editors and ICKDSF today do not handle low level functions for HDDs and optical disc drives such as writing timing marks, and they cannot reinitialize a modern disk that has been degaussed or otherwise lost the factory formatting.
High-level formatting[edit]
High-level formatting is the process of setting up an empty file system on a disk partition or logical volume and, for PCs, installing a boot sector. This is a fast operation, and is sometimes referred to as quick formatting.
The entire logical drive or partition may optionally be scanned for defects, which may take considerable time.
In the case of floppy disks, both high- and low-level formatting are customarily performed in one pass by the disk formatting software. 8-inch floppies typically came low-level formatted and were filled with a format filler value of
0xE5.[17][NB 4] Since the 1990s, most 5.25-inch and 3.5-inch floppies have been shipped pre-formatted from the factory as DOS FAT12 floppies.
In current IBM mainframe operating systems derived from OS/360 or DOS/360, this may be done as part of allocating a file, by a utility specific to the file system or, in some older access methods, on the fly as new data are written.
Host protected area[edit]
The host protected area, sometimes referred to as hidden protected area, is an area of a hard drive that is high level formatted so that the area is not normally visible to its operating system (OS).
Reformatting [edit]
Reformatting is a high-level formatting performed on a functioning disk drive to free the medium of its contents. Reformatting is unique to each operating system because what actually is done to existing data varies by OS. The most important aspect of the process is that it frees disk space for use by other data. To actually "erase" everything requires overwriting each block of data on the medium; something that is not done by many high-level formatting utilities.
Reformatting often carries the implication that the operating system and all other software will be reinstalled after the format is complete. Rather than fixing an installation suffering from malfunction or security compromise, it is sometimes judged easier to simply reformat everything and start from scratch. Various colloquialisms exist for this process, such as "wipe and reload", "nuke and pave", "reimage", etc.
Formatting[edit]
DOS, OS/2 and Windows[edit]
format command: Under MS-DOS, PC DOS, OS/2 and Microsoft Windows, disk formatting can be performed by the
formatcommand. The format program usually asks for confirmation beforehand to prevent accidental removal of data, but some versions of DOS have an undocumented /AUTOTEST option; if used, the usual confirmation is skipped and the format begins right away. The WM/FormatC macro virus uses this command to format drive C: as soon as a document is opened.
Unconditional format: There is also the
/U parameter that performs an unconditional format which under most circumstances overwrites the entire partition,[22] preventing the recovery of data through software. Note however that the /U switch only works reliably with floppy diskettes (see image to the right). Technically because unless /Q is used, floppies are always low level formatted in addition to high-level formatted. Under certain circumstances with hard drive partitions, however, the /Uswitch merely prevents the creation of unformat information in the partition to be formatted while otherwise leaving the partition's contents entirely intact (still on disk but marked deleted). In such cases, the user's data remain ripe for recovery with specialist tools such as EnCase or disk editors. Reliance upon /U for secure overwriting of hard drive partitions is therefore inadvisable, and purpose-built tools such as DBAN should be considered instead.
Overwriting: In Windows Vista and upwards the non-quick format will overwrite as it goes. Not the case in Windows XP and below.[23]
OS/2: Under OS/2, if you use the
/L parameter, which specifies a long format, then format will overwrite the entire partition or logical drive. Doing so enhances the ability of CHKDSK to recover files.Unix-like operating systems[edit]
High-level formatting of disks on these systems is traditionally done using the
mkfs command. On Linux (and potentially other systems as well) mkfs is typically a wrapper around filesystem-specific commands which have the name mkfs.fsname, where fsname is the name of the filesystem with which to format the disk.[24] Some filesystems which are not supported by certain implementations of mkfs have their own manipulation tools; for example Ntfsprogs provides a format utility for the NTFS filesystem.
Some Unix and Unix-like operating systems have higher-level formatting tools, usually for the purpose of making disk formatting easier and/or allowing the user to partition the disk with the same tool. Examples include GNU Parted (and its various GUI frontends such as GParted and the KDE Partition Manager) and the Disk Utilityapplication on Mac OS X.
Recovery of data from a formatted disk[edit]
 | This section possibly contains original research. (March 2011) (Learn how and when to remove this template message) |
As in file deletion by the operating system, data on a disk are not fully erased during every[25] high-level format. Instead, the area on the disk containing the data is merely marked as available, and retains the old data until it is overwritten. If the disk is formatted with a different file system than the one which previously existed on the partition, some data may be overwritten that wouldn't be if the same file system had been used. However, under some file systems (e.g., NTFS, but not FAT), the file indexes (such as $MFTs under NTFS, inodes under ext2/3, etc.) may not be written to the same exact locations. And if the partition size is increased, even FAT file systems will overwrite more data at the beginning of that new partition.
From the perspective of preventing the recovery of sensitive data through recovery tools, the data must either be completely overwritten (every sector) with random data before the format, or the format program itself must perform this overwriting, as the DOS
FORMAT command did with floppy diskettes, filling every data sector with the format filler byte value (typically 0xF6).
However, there are applications and tools, especially used in forensic information technology, that can recover data that has been conventionally erased. In order to avoid the recovery of sensitive data, governmental organization or big companies use information destruction methods like the Gutmann method.[citation needed][26] For average users there are also special applications that can perform complete data destruction by overwriting previous information. Although there are applications that perform multiple writes to assure data erasure, any single write over old data is generally all that is needed on modern hard disk drives. The ATA Secure Erase can be performed by disk utilities to quickly and thoroughly wipe drives.[27][28] Degaussing is another option; however, this renders the drive unusable.[27]
